Automatic cap of the whole circle, the whole tail function: can automatically deformation of the bottle cap round, after the end of the automatic labeling; do not have to worry about deformation due to the bottle on the machine difficult;
Automatic stop waiting: no film or no bottle cap, the machine automatically shut down waiting; wait until there is a film and a bottle of the machine automatically boot;
Automatic clearance stop: press the "clear" function keys, the machine will automatically split the bottle on the bottle all the label and empty the label, the machine automatically shut down;
Automatic shutdown or box; production yield to set the output when the machine automatically shut down or box;
Automatic fault diagnosis: display the cause of the malfunction, automatic shutdown waiting;
Security protection: cover and secondary labeling area above, if foreign body into the security area, the machine automatically shut down protection;
Overheating protection: when the actual labeling temperature reaches or exceeds the set alarm value, the machine automatically shut down protection;
Product visual inspection: additional configuration, set their own product labeling quality standards, where the standard products are not, automatically removed.
{C}{C}{C}{C}
Technical parameter :
voltage | AC 220V |
Operating Voltage | AC 220V and DC 24V |
Power | About 3kw |
Air supply pressure | 6-8kgf/c㎡ |
Working pressure | 5.5-6kgf/cm2 |
Output capacity | 4500 C/H |
Machine specifications | 2800×1000×1850mm |
Film (standard) specifications | Thick 0.05-0.10mm |
Width | 57~70mm |
Center distance | 58mm |
Safety operation rules for film sticking machine
1. Before starting the machine, check whether the fastening bolts of the equipment are loose, and it is strictly forbidden to store any debris on the machine table.
2. Turn on the main power switch, and after powering on, observe whether the equipment is operating normally and whether there is any abnormal sound or burning smell.
3. After the equipment is started, check that it meets the requirements and then mass-produce it without tearing the film tightly, whether it is in the middle, and formal production is not allowed.
4. Consciously do the "first three inspections" and frequently self-inspect the quality of work pieces. You can't stick the film to the end in one self-test.
5. During operation, the hand can only be 30 cm away from the drum, and cannot enter the dangerous place. It is strictly forbidden to operate, talk, and lose concentration. Clothes and long hair must be tightened and not scattered.
6. The machine must be shut down and the power supply must be cut off when the work is completed, failure or abnormal situation occurs. It is strictly forbidden to perform maintenance during operation or when the power is on; it is strictly forbidden to force it with illness.
7. Turn off the power switch and clean the work site. The materials are stored in an orderly manner with safe passages.
